Automatic screw and washer assembly machine

screw and washer combine machine

I. technical parameters

Efficiency:  60-70pcs/min

Function: automatic feeding and assembly screw/nut and washer, automatic discharging.

Power supply: AC220V single-phase

Air Source: 0.6Mpa

Machine Dimension: 1150*950*1300mm (L* W* H)

Controlling system: Siemens PLC+ touch screen
Discharge:  auto unloading

II. Description:

1. this SPM machine is designed for screw and washer, the material are loading and feeding by vibrator bowl, automatic assembly and automatic discharging.

2. automatic sorting the screw with required orientation

3. screw dropping with fiber check, guaranteed the number of screws.

4. one worker can operate 3 to 5 machineserate 3 to 5 machines
